| 1 |
 |
Screw, M5x10
#1
100010953-0006
|
100010953-0006 |
|
|
| 2 |
|
Control Panel
#2
100770618-0001
|
100770618-0001 |
|
|
| 3 |
|
Step Bolt,M6x15
#3
100760450
|
100760450 |
|
|
| 4 |
|
Front Cover
#4
100760460-0001
|
100760460-0001 |
|
|
| 5 |
|
Wire Jacket
#5
100711831
|
100711831 |
|
|
| 6 |
|
Bolt, M6x12
#6
100011261-0014
|
100011261-0014 |
|
|
| 7 |
|
Wire Harness
#7
100770634-0001
|
100770634-0001 |
|
|
| 8 |
|
Inverter
#8
100768167
|
100768167 |
|
|
| 9 |
|
Engine
#9
1ZZZDF651
|
1ZZZDF651 |
|
|
| 10 |
|
Column
#10
100758367
|
100758367 |
|
|
| 11 |
|
DC Voltage Regulator
#11
100768170
|
100768170 |
|
|
| 12 |
|
Push Lug
#12
100758377
|
100758377 |
|
|
| 13 |
|
Across Bar
#13
100758373
|
100758373 |
|
|
| 14 |
|
Nut, M6
#14
100011452-0010
|
100011452-0010 |
|
|
| 15 |
|
Damping Pad
#15
100021127
|
100021127 |
|
|
| 16 |
|
Left Hull
#16
100772137-0001
|
100772137-0001 |
|
|
| 17 |
|
Left Cover Board Assembly
#17
100771953-0001
|
100771953-0001 |
|
|
| 18 |
|
Phillips Bolt
#18
100072713-0002
|
100072713-0002 |
|
|
| 19 |
|
Fuel Cap
#19
100747741
|
100747741 |
|
|
| 20 |
|
Fuel Tank Outlet Seal ring
#20
100760463
|
100760463 |
|
|
| 21 |
|
Rubber Ring
#21
100714561-0001
|
100714561-0001 |
|
|
| 22 |
|
Lamina Lucida
#22
100714560
|
100714560 |
|
|
| 23 |
|
Upper Housing Assem
#23
100760445-0001
|
100760445-0001 |
|
|
| 24 |
|
Upper Handle Assembly
#24
100758379-0001
|
100758379-0001 |
|
|
| 25 |
|
Handle Coupling Bolt
#25
100760468
|
100760468 |
|
|
| 26 |
|
Bolt, M6x22
#26
100011267-0011
|
100011267-0011 |
|
|
| 27 |
|
Washer, 6,5x1,5x18,2
#27
100010437-0002
|
100010437-0002 |
|
|
| 28 |
|
Fuel Hose 4x8x785
#28
100766698-0001
|
100766698-0001 |
|
|
| 29 |
|
Fuel Hose 4x8x410
#29
100766699-0001
|
100766699-0001 |
|
|
| 30 |
|
Clip
#30
100762153
|
100762153 |
|
|
| 31 |
|
Fuel Tee Pipe
#31
100160310
|
100160310 |
|
|
| 32 |
|
Damping Pad
#32
100009075
|
100009075 |
|
|
| 33 |
|
Fuel Tank
#33
100766550
|
100766550 |
|
|
| 34 |
|
Fuel Tank Nipple
#34
100714546
|
100714546 |
|
|
| 35 |
|
Clamp
#35
100005148
|
100005148 |
|
|
| 36 |
|
Fuel Hose 4x8x145
#36
100766700-0001
|
100766700-0001 |
|
|
| 37 |
|
Clip
#37
100000672
|
100000672 |
|
|
| 38 |
|
Fuel Tee Pipe
#38
100731971-0001
|
100731971-0001 |
|
|
| 39 |
|
Fuel Hose 4x8x110
#39
100766701-0001
|
100766701-0001 |
|
|
| 40 |
|
Bearing Clamp Ring 5,5x14
#40
100087972
|
100087972 |
|
|
| 41 |
|
Column
#41
100758365
|
100758365 |
|
|
| 42 |
|
Column
#42
100758363
|
100758363 |
|
|
| 43 |
|
Gasket, Muffler
#43
100760444
|
100760444 |
|
|
| 44 |
|
Rear Cover
#44
100760440-0001
|
100760440-0001 |
|
|
| 45 |
|
Service Window
#45
100760443
|
100760443 |
|
|
| 46 |
|
Column
#46
100758371
|
100758371 |
|
|
| 47 |
|
Push Lug
#47
100758375
|
100758375 |
|
|
| 48 |
|
Switch Assembly
#48
100760451
|
100760451 |
|
|
| 49 |
|
Right Hull
#49
100772139-0001
|
100772139-0001 |
|
|
| 50 |
|
Lithium Battery
#50
100762499
|
100762499 |
|
|
| 51 |
|
Remote Controler
#51
100765715
|
100765715 |
|
|
| 52 |
|
Self-tappling Screw, ST5x16
#52
100762500
|
100762500 |
|
|
| 53 |
|
Bolt M5x12
#53
100098636-0001
|
100098636-0001 |
|
|
| 54 |
|
Right Cover Board Assembly
#54
100771951-0001
|
100771951-0001 |
|
|
| 55 |
|
Screw, M4x10
#55
100010946-0010
|
100010946-0010 |
|
|
| 56 |
|
Engine Front Board
#56
100759245
|
100759245 |
|
|
| 57 |
|
Engine Rear Board
#57
100759247
|
100759247 |
|
|
| 58 |
|
Nut, M8
#58
100011464-0005
|
100011464-0005 |
|
|
| 59 |
|
Bolt, M6x20
#59
100011266-0010
|
100011266-0010 |
|
|
| 60 |
|
Bolt, M8x25
#60
100011551-0004
|
100011551-0004 |
|
|
| 61 |
|
Damping Pad
#61
100760467
|
100760467 |
|
|
| 62 |
|
Framework Board
#62
100758362
|
100758362 |
|
|
| 63 |
|
Clip
#63
100000656
|
100000656 |
|
|
| 64 |
|
Clip 5,2x13
#64
100070831
|
100070831 |
|
|
| 65 |
|
Box Base
#65
100760438
|
100760438 |
|
|
| 66 |
|
Shroud Cover
#66
100760449
|
100760449 |
|
|
| 67 |
|
Clip 23
#67
100732285
|
100732285 |
|
|
| 68 |
|
Connetion Plate
#68
100758383
|
100758383 |
|
|
| 69 |
|
Wheel Shaft Assembly
#69
100758591
|
100758591 |
|
|
| 70 |
|
Wheel
#70
100150456
|
100150456 |
|
|
| 71 |
|
Bolt, M8x12
#71
100011229-0002
|
100011229-0002 |
|
|
| 72 |
|
Adjustable Handle
#72
100758382
|
100758382 |
|
|
| 73 |
|
Bolt, M6x32
#73
100033038-0003
|
100033038-0003 |
|
|
| 74 |
|
Rubber Cap
#74
100150594
|
100150594 |
|
|
